The Wireless Game Boy Controller: Turning the Handheld Into a Gamepad for Everything
For thirty years the Game Boy has been the thing you play. This little cartridge flips that idea completely. Slot it in and the handheld stops being a console and becomes something else entirely: a wireless controller for almost everything else in the room. It is one of the cleverest modern homebrew ideas to pass through the collection, and it comes in two halves, a transmitter that lives in the Game Boy and a family of receivers that plug into whatever you want to play.
The transmitter: a Game Boy that broadcasts
The piece in the collection is the transmitter cartridge, made by the Australian homebrew maker insideGadgets. It looks like an ordinary game, a plain clear or grey Game Boy cartridge, and it loads like one too. But instead of a game, it runs a small program that reads the console's eight buttons, up, down, left, right, start, select, B and A, and beams them out over a low-latency radio link. Every two milliseconds it checks the buttons and sends a fresh packet, and it reaches at least eight metres in line of sight. Importantly, this is not Bluetooth; it is a simple dedicated radio, which is part of why it feels so responsive.
The GB transmitter works across the whole classic family, the original DMG, the Game Boy Pocket, the Game Boy Color and the Game Boy Advance, so whichever grey brick you love most can become the controller. One charming quirk: because the wireless packets run through the cartridge, you may hear a faint buzzing from the console speaker as you play. That is not a fault, it is simply the sound of the data being sent, and it is louder on an original Game Boy.
A receiver for almost everything
The transmitter is only half of the trick. On its own it broadcasts into thin air; it needs a receiver to catch the signal, and this is where the system becomes genuinely remarkable. insideGadgets offers a whole range of receivers, each shaped to plug into a different machine, so a single Game Boy can drive a surprising spread of hardware.
The most flexible is the USB receiver, a simple Type-A dongle that presents itself as a standard USB gamepad. Plug it into a PC running Windows or Linux, a Raspberry Pi running RetroPie, or even a MiSTer FPGA or an Android phone over USB, and your Game Boy becomes a controller for emulators and modern software alike. From there the receivers get more specialised, each one built for a real console's controller port. The NES receiver plugs into a Nintendo controller socket to play NES games; the Super Nintendo receiver does the same on a SNES, for games that do not lean on the X and Y buttons. The Nintendo 64 receiver slots into an N64 port, mapping Select to the Z trigger; the GameCube receiver reaches the Nintendo GameCube for games that only need B and A. And the WiiMote expansion receiver clips onto a Wii remote and pretends to be a Classic Controller, which also opens the door to the NES and SNES Classic Mini consoles. There is even an Atari 2600 receiver for its classic joystick port, reaching right back to the 1970s.
Because the buttons are so simple, the same receiver works whether you use the Game Boy transmitter here or its sibling, a separate GBA transmitter cart that adds the shoulder buttons L and R and covers the Game Boy Advance, Game Boy Micro and the DS family. Buy one receiver for your console of choice, and either cartridge can drive it.
The loop that makes collectors smile
The most delightful uses are the ones that fold back on themselves. Pair the transmitter with the Super Nintendo receiver and slot a Super Game Boy into the SNES, and you can play Game Boy games on the television while holding a Game Boy as the controller. The GameCube receiver pulls the same trick through the Game Boy Player, letting a wireless Game Boy control Game Boy games running on the big screen. There is something wonderfully circular about a handheld becoming the remote control for its own library, and it is exactly the kind of playful engineering that makes the homebrew scene worth documenting.
Setting up, and one honest caveat
Pairing is refreshingly low-tech. You hold Start as the transmitter boots to pick a channel and address, note them down, press A to transmit, and the receivers you plug in blink twice to confirm they are listening. One cartridge can talk to several receivers at once, and you can set more carts to the same channel so friends can join in, though only one transmitter should be active at a time to avoid them clashing.
One honest note, straight from the maker: there is no encryption on the link. For a living-room setup that means nothing at all, but in principle someone nearby could interfere with the signal. It is a small caveat on an otherwise ingenious device, and a reminder that this is hand-built homebrew rather than a mass-market product, each unit assembled and tested by hand in Australia. To see the Wireless Game Boy Controller and the rest of the collection's modern oddities, come and explore the Game Boy Museum.
